Gate Valve-200MM

Product Specification

* GATE VALVE OF SIZE: 200 MM

* CLASS-150

* OS and Y TYPE BOLTED BONNET RISING SPINDLE DESIGN AS PER API 600 and TESTING API 598

* FLANGE AS PER ASME B16.5 (RF).

* BODY and BONNET: ASTM A216 WCB

* SEAT RING: ASTM A105+STELLITE 6/ASTM 216 WCB+13% CR

* DISC: ASTM A217 GR CA 15

* STE M: ASTM A182 GR F6A

* GASKET: SS SPIRAL WOUND WITH GRAPHITE FILLER

* GLAND PACKING: GRAPHITE/GRAPHOIL

* HAND WHEEL: SG IRON/STEEL

NOTE: Test Certificate, Warranty/Guarantee Certificate to Accompany Supply

Application

In most cases, a gate valve is used to totally stop fluid flow or, when fully opened, to allow full flow in a pipeline. As a result, it can be utilised either totally closed or fully open. A gate valve's components include the valve body, seat, and disc, as well as the spindle, gland, and wheel that controls the valve.
