Gate Valve-125MM

Product Specification

* GATE VALVE MOC BODY/BONNET/COVER CARBON STEEL

* MATERIAL SPEC: BODY/BONNET

* ASTM A216 GRADE WCB SIZE 125MM END CONNECTION

* FLANGED PRESSURE CLASS - CLASS 150 / PN16 END-END/FACE-FACE DISTANCE

* 254MM+/-2 VALVE OPERATION

* HAND WHEEL WORKING TEMPERATURE

* AMBIENT TEST STANDARD

* API 598 DESIGN SPECIFICATION - API 600 MOC

* TRIM13% CHROMIUM STEEL

* SPINDLE TYPE- RISING

* GASKET TYPE- SPIRAL WOUND

* MATERIAL: STAINLESS STEEL 304 WITH GRAPHITE GLAND

* PACKING MATERIAL: GRAPHITE

* PITCH CIRCLE DIAMETER: 215.9 MM WITH 8 NUMBER OF HOLE

NOTE:Test Certificate, Warranty/Guarantee Certificate to Accompany Supply

Application

In most cases, a gate valve is used to totally stop fluid flow or, when fully opened, to allow full flow in a pipeline. As a result, it can be utilised either totally closed or fully open. A gate valve's components include the valve body, seat, and disc, as well as the spindle, gland, and wheel that controls the valve.
