Gate Valve-10 Inch

Product Specification

* GATE VALVE TYPE

* DESIGN : WEDGE MOC BODY/BONNET/COVER

* CARBON STEEL MATERIAL SPEC BODY/BONNET

* ASTM A216 GRADE WCB SIZE 10 INCH END CONNECTION

* FLANGED PRESSURE CLASS

* CLASS 150 MOC

* SPINDLE/SHAFT/STEM : STAINLESS STEEL 410 MOC,

* WEDGE/DISC/KNIFE-PLATE : 13% CHROMIUM STEEL VALVE OPERATION :

* HAND WHEEL WITH RISING STEM TEST STANDARD : API598 / EN 12266 / ISO 5208

* DESIGN SPECIFICATION :ASME B16.34 / API 600 FLANGE,

* FACING : RAISED FACE MOC

* SEAT: 13% CHROMIUM STEEL

* PACKING MATERIAL: PTFE / GRAPHOIL

* GASKET TYPE: SPIRAL WOUND

* MATERIAL: STAINLESS STEEL 304 WITH GRAPHOIL

* FACE TO FACE DESIGN SPEC: AS ME B16.10 / BS 2080

* END CONNECTION DESIGN SPEC: ASME B16.5

* STUD MATERIAL: STAINLESS STEEL, WITH COMPANION FLANGE, FASTENER AND GAS KET,

NOTE: Test and Warranty/Guarantee Certificate to Accompany Supply

Application

In most cases, a gate valve is used to totally stop fluid flow or, when fully opened, to allow full flow in a pipeline. As a result, it can be utilised either totally closed or fully open. A gate valve's components include the valve body, seat, and disc, as well as the spindle, gland, and wheel that controls the valve.
