AC LT Gear Motor-4KW

Product Specification

*Motor Power:4.0 kW

* Drive Shaft Speed:57 R/Min.

*Torque:672 Nm

* Service Factor fB:3.4

* Corrosion Protection:CORO2

* Painting:RAL 7001

* Mounting:B3

*Direction of Terminal Box:I/A

* Net Weight per Piece:312

* Frequency Range:5-50-55 Hz

* Voltage:59-415-415 V

*Power:0.4-4.0-4.3 kW

*Synchronous Speed:5.7-57-63 R/Min

*Current (Approx):10-0-10.0-10.7 A

*Gear Designs:

*Type:Helical Gears BG70, Arrangements Key:Foot Design, Gearbox Reduction:17.68,
Special Designs Arrangement of the Motor:

*Type:3 Phase Motor in Roller Table Design in Non-Ventilated Version

* Power Factor (cos phi):0.63

*Insulation Class:H, Operating Mode:S5

* Permissible Blocking (Stoppage) Time Under Full Voltage:2 Min.

* Assigned Speed:970, Protection:IP 65

* Terminal Box:TB 322, IEC Frame Size:180, Motor Nominal Torque:39 Nm

* Motor Starting Torque:140 Nm, Motor Maximum Torque:184 Nm

*Motor Inertia:0.245 Kgm2

* Starting Current:77.0 Amps

*Acceleration Current (Approx):28 Amps

*No Load Current:7.7 Amps

* Maximum Torque Capacity of Gear Box:2300 Nm

Application

The gear reducer is typically designed to increase the output torque while retaining a compact size, without increasing the motor's power consumption.
